| Item |
Project |
Parameters |
| Printing Parameters |
Printing Method |
Line Therma |
| Resolution |
203dpi; Optional 300dpi |
| Print Instruction |
Tspl (Customizable Cpcl/Zpl/Ep) |
| Print Width |
104mm |
| Printing Speed |
127mm/s; Optional 150mm/s |
| Print Head Life |
50 Km (Label Paper); 150km (Continuous Paper) |
| Operating Platform |
Usb Version: Windows/Linux/Mac Os Bluetooth Version: Windows/Android/Ios |
| Run Memory Ram |
2Mb |
| Flash |
2Mb (Usb Version); 4mb (Bluetooth Version) |
| Connection Method |
Usb/Usb+Bluetooth (Wifi Can Be Customized) |
| Opening Method |
Side Button Toggle |
| Heating Head Temperature Detection |
Thermistor |
| Paper Parameters |
Paper Type |
Label Paper, Continuous Paper, Black Label Paper, Stacked Paper |
| Paper Loading Method |
Easy Paper Loading/Automatic Feeding |
| Paper Width |
38-120mm |
| Label Height |
Minimum 30mm; Maximum 250mm |
| Label Width |
Minimum 38mm; Maximum 112mm |
| Media Thickness |
0.06-0.18mm |
| Paper Cutting Method |
Manual Tearing |
| Axis Detection Method |
Mechanical Detection Switch |
| Out Of Paper Detection |
Optocoupler |
| Print Function |
Automatic Paper Recognition, Intelligent Paper Return And Suction, Reprint For Lacking Paper, Defective Pixel Detection And Other Functions |
| Key Parameters |
Key Operation |
Power Button (Black Power Button On The Rear Side) Lid Opening Button (Opening Button On Both Sides) Feed Key (Black Feed Key Above) |
| Key Operation Function In This Scenario |
1. Turn Off, Long Press Feed Key And Power Key : Self-Check Page Printing
2. Standby, Long Press Feed Key For 3 Seconds: Enter The Face-Sheet Learning Mode
3. Open Lid And Press Feed Key For 10 Seconds: Restore Factory Settings
4. Standby, Short Press Feed Key: Automatically Enter a Blank Sheet
5. During Continuous Printing, Short Press Feed Key: Printing Pauses
6. Pause Printing, Short Press Feed Key: Continue Printing
|
| ndicator Status Description |
The Indicator Light Keeps On: Normal Standby Indicator Light Flashes: Buzzer Alarm |
| Buzzer Alarm Prompt |
2 Beeps: Printer Head Error
3 Beeps: Lacking Paper
5 Sounds: Overheating Error
6 Sounds: Wrong Opening
7 Sounds: Wrong Stitch Mark
|
| Barcode Parameters |
Support Language |
Support Most Languages, Individual Languages Need To Be Customized |
| Character |
Standard Gb18030 Simplified Chinese |
| Character Size |
Ascii Font a: 12×24
Ascii Font b: 9×17
Chinese Characters: 24×24
|
| Extended Character Table |
Cp437，Cp850，Cp852，Cp860，Cp863，Cp865，Cp866，Wpc1250， Wpc1251，Wpc1252，Wpc1253，Wpc1254 |
| Barcode Type |
One-Dimensional Code: Code 39，39c，i25，Code 93，Itf25，Ean128， Code 128，Codabar，Ean-8，Ean8+2，Ean8+5，Ean-13，Ean13+2，Ean13+5， Upc-a，Upca+2，Upca+5，Upc-e，Upce+2，Upce+5 Msic，Itf14，Ean14， Code11，Post
QR Code: Qrcode, Pdf417 (Optional)
|
| Font And Barcode Rotation |
Supports |
| Packing Specification |
Usb Interface |
1*Standard Usb |
| Charging Port |
DC |
| Adapter |
24v/2.5a |
| Accessories |
■Power Adapter ■Power Cord ■Usb Data Cable ■Quick Safety Guide |
| Package |
■Kraft Paper ■Pearl Cotton Partition ■Pearl Cotton Lining |
| Product Weight |
1kg |
| Product Size |
222x102x96mm |
| Outer Box Size (Single Unit) |
26x13.6x19.1cm, 1.71kg |
| Outer Box Size (8 Units) |
53x39.6x29cm, 16kg |
| Temperature |
Working Temperature: 0-45℃; Storage Temperature: -10-60℃ |
| Humidity |
Working Humidity: 20-90%; Storage Humidity: 10-90% |
| Certification Specifications |
Certification Requirements |
CCC, CE, FCC |
